Aiguille industrielle · 134-35 EK
134-35 EK R EK Chromium
134-35 EK
R EK
Chromium
1
Point style R EK - Cloth point Normal round point with lightly sharp form • Eccentric point at 180° • Normal round point with lightly sharp form • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather Coating Chromium Needle with standard chrome coating. Special(s): Eccentric point at 180° Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 771122 | — | 100 pièces | 0.898 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Needle size Asia | 12 |
| Length butt to eye | 38.1 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 32:10 |
| Catalog designation | 381200AC01R EK |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Eccentric point at 180° |
| Recommended for | Woven fabrics, Thin leather |
| Examples of use | Shirts, Blouses, Trousers |
| Needle size | 80 Nm |
| Point style | R EK - Cloth point |
| Needle system | 134-35 EK |
| Needle system family | 134-35 |
| Variant | EK |
| Pack standard | N-S-00017 – Standard Packaging |
