Aiguille industrielle · 134-35

134-35 LR GEBEDUR™

Système134-35

PointeLR

FinitionGEBEDUR™

Tailles6

Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
100/16	762852	42.8 mm	100 pièces	0.94 g
110/18	762862	42.9 mm	100 pièces	0.971 g
120/19	762872	43 mm	100 pièces	0.984 g
130/21	769912	43.1 mm	100 pièces	0.996 g
140/22	763902	43.2 mm	100 pièces	1.016 g
150/	769922	43.4 mm	100 pièces	1.078 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	38.1 mm
Coating	GEBEDUR™
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	LR
Canu designation	32:10
Catalog designation	381200AD01LR
Further point designations	NRTW
Further point designations 02	RTW
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	LR - Cutting point
Needle system	134-35
Needle system family	134-35
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	134-35 LR
System designation 2	DPX35 LR
System designation 3	2134-35 LR
Seam	Attach frame
Needle recommendation	Quality plus choice
