Aiguille industrielle · 134-35

134-35 R Chromium

Système134-35

PointeR

FinitionChromium

Tailles13

Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
70/10	716712	42.4 mm	100 pièces	0.845 g
75/11	763402	42.5 mm	100 pièces	0.706 g
80/12	716722	42.5 mm	100 pièces	0.894 g
90/14	716732	42.6 mm	100 pièces	0.914 g
100/16	716742	42.8 mm	100 pièces	0.928 g
110/18	716752	42.9 mm	100 pièces	0.941 g
120/19	716762	43 mm	100 pièces	0.971 g
130/21	716772	43.1 mm	100 pièces	0.985 g
140/22	716782	43.2 mm	100 pièces	1.023 g
150/	716792	43.4 mm	100 pièces	1.067 g
160/23	716802	43.5 mm	100 pièces	1.11 g
180/24	716822	43.7 mm	100 pièces	1.155 g
200/25	716832	44 mm	100 pièces	1.064 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	38.1 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	R
Canu designation	32:10
Catalog designation	381200AC01R
Further point designations	SET
Further point designations 02	RD
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	R - Cloth point
Needle system	134-35
Needle system family	134-35
Customary needle designations	DPX35
System designation 2	DPX85
System designation 3	2134-35
System designation 4	2134-85
System designation 5	SY 7217
System designation 6	SY 7225
Needle recommendation	Quality choice
