Aiguille industrielle · 134-35

134-35 R GEBEDUR™

Système134-35

PointeR

FinitionGEBEDUR™

Tailles7

Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle. Recommended for: Medium-weight woven fabrics, Leather for clothing, Artificial leather Examples of use: Jeans, Workwear, Suits, Accessories, Shoes, Leather clothing, Covers for upholstery

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
90/14	762812	42.6 mm	100 pièces	0.925 g
100/16	762822	42.8 mm	100 pièces	0.941 g
110/18	762832	42.9 mm	100 pièces	0.962 g
120/19	760952	43 mm	100 pièces	0.991 g
130/21	760962	43.1 mm	100 pièces	0.985 g
140/22	760972	43.2 mm	100 pièces	1.023 g
160/23	767342	43.5 mm	100 pièces	1.136 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	38.1 mm
Coating	GEBEDUR™
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	R
Canu designation	32:10
Catalog designation	381200AD01R
Further point designations	SET
Further point designations 02	RD
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	R - Cloth point
Needle system	134-35
Needle system family	134-35
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	DPX35
System designation 2	2134-35
System designation 3	2134-85
System designation 4	DPX85
Seam	Attach frame
Needle recommendation	Quality plus choice
