Aiguille industrielle · 134 ER
134 ER R ER Chromium
134 ER
R ER
Chromium
2
Point style R ER - Cloth point Normal round point with lightly sharp form • Eccentric point at 90° • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather Coating Chromium Needle with standard chrome coating. Special(s): Eccentric point at 90° Recommended for: Woven fabrics Examples of use: Trousers, Draperies
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 100/16 | 713992 | — | 100 pièces | 0.899 g |
| 110/18 | 714002 | — | 100 pièces | 0.738 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | RS ER |
| Canu designation | 20:55 |
| Catalog designation | 339200AC01RS ER |
| Further point designations | R-SPI |
| Further point designations 02 | S SET |
| Further point designations 03 | SPI |
| Further point designations 04 | R-SP |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Eccentric point at 90° |
| Recommended for | Woven fabrics |
| Examples of use | Trousers, Draperies |
| Point style | R ER - Cloth point |
| Needle system | 134 ER |
| Needle system family | 134 |
| Variant | ER |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DPXP9 |
| System designation 2 | PFX134 ER |
| System designation 3 | 797 ER |
| System designation 4 | SY 6797 |
