Aiguille industrielle · 134

134 FG Chromium

Système134

PointeFG

FinitionChromium

Tailles8

Point style FG - Cloth point Medium ball point • Round point with medium ball • Suitable for loose-knit fabrics, elastic material and material containing rubber or elastane Coating Chromium Needle with standard chrome coating. Recommended for: Elastic fabrics Examples of use: Lace, Underwear, Bandages

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
60/8	717732	38.1 mm	100 pièces	0.855 g
65/9	717742	38.1 mm	100 pièces	0.857 g
100/16	717792	38.6 mm	100 pièces	0.891 g
110/18	717802	38.7 mm	100 pièces	0.919 g
120/19	717812	38.8 mm	100 pièces	0.905 g
125/20	763472	38.9 mm	100 pièces	0.935 g
130/21	717822	38.9 mm	100 pièces	0.927 g
140/22	717832	39 mm	100 pièces	0.955 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	33.9 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	SUK
Canu designation	20:05
Catalog designation	339200AC01FG
Further point designations	SUK
Further point designations 02	B BALL
Further point designations 03	M BALL
Further point designations 04	SI
Further point designations 05	BPM
Further point designations 06	LAC
Further point designations 07	R SUK
Further point designations 08	U
Further point designations 09	R KB
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	FG - Cloth point
Needle system	134
Needle system family	134
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	DPX5 B
System designation 2	DPX7 B
System designation 3	DPX134 B
System designation 4	PFX134 B
System designation 5	MTX797 B
System designation 6	135X5 SUK
System designation 7	135X7 SUK
System designation 8	797 SUK
System designation 9	1844 SUK
System designation 10	SY 1901
System designation 11	SY 1955
