Aiguille industrielle · 134 K
134 K FFG Chromium
134 K
FFG
Chromium
2
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Special(s): Short shank Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 718312 | 36.9 mm | 100 pièces | 0.859 g |
| 90/14 | 718322 | 37.1 mm | 100 pièces | 0.895 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Shank length | 13.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SES |
| Canu designation | 19:25 |
| Catalog designation | 339200AC03FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Short shank |
| Point style | FFG - Cloth point |
| Needle system | 134 K |
| Needle system family | 134 |
| Variant | K |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | PFX134 K J |
| System designation 2 | PFX797K J |
| System designation 3 | 135X9 SES |
| System designation 4 | 135X29 SES |
| System designation 5 | 556KH SES |
| System designation 6 | 797KH SES |
| System designation 7 | 797KSP SES |
| System designation 8 | SY1902 |
| System designation 9 | SY1910 |
| System designation 10 | SY6795 |
