Aiguille industrielle · 134 KK
134 KK D Chromium
134 KK
D
Chromium
4
Point style D - Cutting point Cutting point • Wide triple-edge cut in leather • Straight seam • Thread slightly elevated • Stitch holes are wide open • Suitable for medium to long stitches Coating Chromium Needle with standard chrome coating. Special(s): Short shank Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 714572 | 38.3 mm | 100 pièces | 0.821 g |
| 90/14 | 714582 | 38.4 mm | 100 pièces | 0.835 g |
| 100/16 | 714592 | 38.6 mm | 100 pièces | 0.885 g |
| 110/18 | 714602 | 38.7 mm | 100 pièces | 0.887 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Shank length | 11.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | TRI |
| Canu designation | 18:60 |
| Catalog designation | 339200AC02D |
| Further point designations | TRI |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Short shank |
| Recommended for | Thin leather |
| Examples of use | Leather clothing, Shoes, Accessories |
| Point style | D - Cutting point |
| Needle system | 134 KK |
| Needle system family | 134 |
| Variant | KK |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | PFX134KK D |
| System designation 2 | 797 KK D |
