Aiguille industrielle · 134 KK
134 KK LR Chromium
134 KK
LR
Chromium
6
Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Special(s): Short shank Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 60/8 | 758232 | 38.1 mm | 100 pièces | 0.611 g |
| 65/9 | 714152 | 38.1 mm | 100 pièces | 0.792 g |
| 80/12 | 714182 | 38.3 mm | 100 pièces | 0.825 g |
| 90/14 | 714192 | 38.4 mm | 100 pièces | 0.845 g |
| 100/16 | 714202 | 38.6 mm | 100 pièces | 0.865 g |
| 110/18 | 714212 | 38.7 mm | 100 pièces | 0.865 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Shank length | 11.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | LR |
| Canu designation | 18:60 |
| Catalog designation | 339200AC02LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Short shank |
| Recommended for | Thin leather |
| Examples of use | Leather clothing, Shoes, Accessories |
| Point style | LR - Cutting point |
| Needle system | 134 KK |
| Needle system family | 134 |
| Variant | KK |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | PFX134 KK LR |
| System designation 2 | MTX134 K |
| System designation 3 | 134 KK LR S |
| System designation 4 | 134 KK VR |
| System designation 5 | 797 KK LR |
| System designation 6 | 797 KK LRS |
| System designation 7 | SY 6760 |
