Aiguille industrielle · 134

134 R Chromium

Système134

PointeR

FinitionChromium

Tailles12

Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
55/7	750722	38 mm	100 pièces	0.858 g
60/8	717442	38.1 mm	100 pièces	0.855 g
65/9	717452	38.1 mm	100 pièces	0.857 g
80/12	717482	38.3 mm	100 pièces	0.866 g
85/13	717492	38.4 mm	100 pièces	0.871 g
125/20	717542	38.9 mm	100 pièces	0.934 g
130/21	717552	38.9 mm	100 pièces	0.927 g
140/22	717562	39 mm	100 pièces	0.955 g
150/	717572	39.2 mm	100 pièces	1.003 g
160/23	717582	39.3 mm	100 pièces	1.034 g
180/24	717602	39.5 mm	100 pièces	1.103 g
200/25	750732	40 mm	100 pièces	1.148 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	33.9 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	R
Canu designation	20:05
Catalog designation	339200AC01R
Further point designations	SET
Further point designations 02	RD
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	R - Cloth point
Needle system	134
Needle system family	134
Customary needle designations	DPX5
System designation 2	135X5
System designation 3	135X7
System designation 4	DPX7
Needle recommendation	Quality choice
