Aiguille industrielle · 134

134 S Chromium

Système134

PointeS

FinitionChromium

Tailles13

Point style S - Cutting point Cutting point • Cuts the leather in the sewing direction • Straight seam • Tight stitch formation with corresponding leather and stitch size • Stitch holes are elongated and clearly visible in the seam • Suitable for medium to large stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
65/9	764142	38.1 mm	100 pièces	0.846 g
70/10	715852	38.2 mm	100 pièces	0.863 g
75/11	715862	38.3 mm	100 pièces	1.01 g
80/12	715872	38.3 mm	100 pièces	0.87 g
90/14	715892	38.4 mm	100 pièces	0.884 g
100/16	715902	38.6 mm	100 pièces	0.893 g
110/18	715912	38.7 mm	100 pièces	0.914 g
120/19	715922	38.8 mm	100 pièces	0.905 g
125/20	758422	38.9 mm	100 pièces	0.924 g
130/21	715932	38.9 mm	100 pièces	0.915 g
140/22	715942	39 mm	100 pièces	0.965 g
150/	715952	39.2 mm	100 pièces	1.008 g
160/23	715962	39.3 mm	100 pièces	1.041 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	33.9 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	S
Canu designation	20:05
Catalog designation	339200AC01S
Further point designations	CR
Further point designations 02	RSP
Further point designations 03	NCR
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	S - Cutting point
Needle system	134
Needle system family	134
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	PFX134 S
