Aiguille industrielle · 134

134 SD Chromium

Système134

PointeSD

FinitionChromium

Tailles8

Point style SD - Cutting point Round point with polished triple cutting edges at the very end of the point • Slightly triangular cut in leather • Straight seam • Thread slightly elevated • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Fine leather goods, Shoes, Embroidery on leather

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
70/10	760062	38.2 mm	100 pièces	0.674 g
75/11	760072	38.3 mm	100 pièces	0.863 g
80/12	751872	38.3 mm	100 pièces	0.866 g
90/14	713852	38.4 mm	100 pièces	0.881 g
100/16	747222	38.6 mm	100 pièces	0.899 g
110/18	747232	38.7 mm	100 pièces	0.919 g
120/19	754932	38.8 mm	100 pièces	0.905 g
140/22	762262	39 mm	100 pièces	0.969 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	33.9 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	SD1
Canu designation	20:05
Catalog designation	339200AC01SD
Further point designations	R-TRI
Further point designations 02	SD 1
Further point designations 03	TRI FACET
Further point designations 04	TRI TIP
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	SD - Cutting point
Needle system	134
Needle system family	134
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	DPX5
System designation 2	DPX7
