Aiguille industrielle · 135X16
135X16 D Chromium
135X16
D
Chromium
5
Point style D - Cutting point Cutting point • Wide triple-edge cut in leather • Straight seam • Thread slightly elevated • Stitch holes are wide open • Suitable for medium to long stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thick leather, Cardboard Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 110/18 | 718642 | 43.6 mm | 100 pièces | 0.984 g |
| 125/20 | 718662 | 44.4 mm | 100 pièces | 0.958 g |
| 130/21 | 718672 | 44.4 mm | 100 pièces | 0.997 g |
| 140/22 | 718682 | 44.5 mm | 100 pièces | 1.048 g |
| 160/23 | 718692 | 44.7 mm | 100 pièces | 1.128 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | D |
| Canu designation | 37:20 |
| Catalog designation | 389200AC01D |
| Further point designations | TRI |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thick leather, Cardboard |
| Point style | D - Cutting point |
| Needle system | 135X16 |
| Needle system family | 135X16 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DPX16 D |
| System designation 2 | 135X17 D |
| System designation 3 | 135X16 D |
| System designation 4 | SY 3379 |
| System designation 5 | 135X17 D |
| Needle recommendation | Quality choice |
