Aiguille industrielle · 135X17
135X17 FG Chromium
135X17
FG
Chromium
8
Point style FG - Cloth point Medium ball point • Round point with medium ball • Suitable for loose-knit fabrics, elastic material and material containing rubber or elastane Coating Chromium Needle with standard chrome coating. Recommended for: Elastic fabrics Examples of use: Lace, Underwear, Bandages
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 65/9 | 771722 | 43.1 mm | 100 pièces | 0.906 g |
| 100/16 | 718922 | 43.5 mm | 100 pièces | 0.975 g |
| 110/18 | 718932 | 43.6 mm | 100 pièces | 0.999 g |
| 120/19 | 771822 | 43.7 mm | 100 pièces | 1.036 g |
| 130/21 | 754072 | 44.4 mm | 100 pièces | 1.005 g |
| 140/22 | 745212 | 44.5 mm | 100 pièces | 1.036 g |
| 160/23 | 746412 | 44.7 mm | 100 pièces | 1.129 g |
| 180/24 | 770622 | 45 mm | 100 pièces | 1.204 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SUK |
| Canu designation | 37:20 |
| Catalog designation | 389200AC01FG |
| Further point designations | SUK |
| Further point designations 02 | B BALL |
| Further point designations 03 | M BALL |
| Further point designations 04 | SI |
| Further point designations 05 | BPM |
| Further point designations 06 | LAC |
| Further point designations 07 | R SUK |
| Further point designations 08 | U |
| Further point designations 09 | R KB |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Point style | FG - Cloth point |
| Needle system | 135X17 |
| Needle system family | 135X17 |
| Customary needle designations | DPX17 B |
| System designation 2 | 135X85 SUK |
| System designation 3 | 135X535 SUK |
| System designation 4 | 2167 SUK |
| System designation 5 | SY 3355 |
| System designation 6 | SY 3357 |
