Aiguille industrielle · 135X17

135X17 R Chromium

Système135X17

PointeR

FinitionChromium

Tailles14

Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
65/9	759692	43.1 mm	100 pièces	0.895 g
70/10	754822	43.2 mm	100 pièces	0.83 g
75/11	757652	43.2 mm	100 pièces	0.909 g
80/12	718782	43.3 mm	100 pièces	0.917 g
85/13	757662	43.3 mm	100 pièces	0.926 g
100/16	718802	43.5 mm	100 pièces	0.965 g
110/18	718812	43.6 mm	100 pièces	0.99 g
120/19	718822	43.7 mm	100 pièces	0.792 g
125/20	718832	44.4 mm	100 pièces	0.985 g
130/21	718842	44.4 mm	100 pièces	1.025 g
140/22	718852	44.5 mm	100 pièces	1.045 g
180/24	718872	45 mm	100 pièces	1.131 g
200/25	718882	45.2 mm	100 pièces	1.26 g
230/26	756362	45.5 mm	50 pièces	0.618 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	38.9 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	R
Canu designation	37:20
Catalog designation	389200AC01R
Further point designations	SET
Further point designations 02	RD
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	R - Cloth point
Needle system	135X17
Needle system family	135X17
Customary needle designations	DPX17
System designation 2	135X85
System designation 3	135X535
System designation 4	2167
System designation 5	SY 3355
System designation 6	SY 3357
Needle recommendation	Quality choice
