Aiguille industrielle · 135X17
135X17 SD Chromium
135X17
SD
Chromium
1
Point style SD - Cutting point Round point with polished triple cutting edges at the very end of the point • Slightly triangular cut in leather • Straight seam • Thread slightly elevated • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Fine leather goods, Shoes, Embroidery on leather
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 100/16 | 759962 | 43.5 mm | 100 pièces | 0.775 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Needle size Asia | 16 |
| Length butt to eye | 38.9 mm |
| Overall length | 43.5 mm |
| Shank length | 16 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SD1 |
| Canu designation | 37:20 |
| Catalog designation | 389200AC01SD |
| Further point designations | R-TRI |
| Further point designations 02 | SD 1 |
| Further point designations 03 | TRI FACET |
| Further point designations 04 | TRI TIP |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thin leather |
| Examples of use | Fine leather goods, Shoes, Embroidery on leather |
| Needle size | 100 Nm |
| Point style | SD - Cutting point |
| Needle system | 135X17 |
| Needle system family | 135X17 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DPX17 SD |
| Seam | Topstitch collar, Decorative seam, Topstitch sleeves, Attach sleeves, Join parts, Join parts, Attach lining, Decorative seam, Heel seam, Join inner and out part, Attach viewing window, Attach inner lining, Topstitch card slots |
| Needle recommendation | Quality choice |
