Aiguille industrielle · 14 SP
14 SP QR Chromium
14 SP
QR
Chromium
1
Point style QR - Cutting point Reverse square point • Cutting position at 0° • For hard and heavy material • Suitable for bag-closing. Coating Chromium Needle with standard chrome coating.
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 150/ | 754492 | 49 mm | 100 pièces | 1.24 g |
Caractéristiques techniques
| Shank diameter | 1.98 mm |
|---|---|
| Length butt to eye | 42.1 mm |
| Overall length | 49 mm |
| Shank length | 13 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B – Straight needle with double groove |
| Canu point | Q |
| Canu designation | 45:13 |
| Catalog designation | 421198BC02QR |
| Further point designations | RSQ |
| Technical sewing application | Bag closing |
| Stitch type class | 400 |
| Needle size | 150 Nm |
| Point style | QR - Cutting point |
| Needle system | 14 SP |
| Needle system family | 14 SP |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | 14 DIA |
| System designation 2 | SY 8750 |
