Aiguille industrielle · 142X5
142X5 RG Chromium
142X5
RG
Chromium
6
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing Examples of use: Jeans, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 719612 | 35.8 mm | 100 pièces | 0.63 g |
| 90/14 | 719622 | 35.8 mm | 100 pièces | 0.815 g |
| 100/16 | 719632 | 35.8 mm | 100 pièces | 0.815 g |
| 110/18 | 719642 | 35.8 mm | 100 pièces | 0.825 g |
| 120/19 | 719652 | 35.8 mm | 100 pièces | 0.835 g |
| 130/21 | 719672 | 35.8 mm | 100 pièces | 0.845 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 31.2 mm |
| Overall length | 35.8 mm |
| Shank length | 9.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Catalog designation | 312200BC01RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Overlock stitch |
| Stitch type class | 500 |
| Point style | RG - Cloth point |
| Needle system | 142X5 |
| Needle system family | 142X5 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DOX5 |
| System designation 2 | SY 1413 |
| System designation 3 | 1778 |
