Aiguille industrielle · 149X5

149X5 RG Chromium

Système149X5

PointeRG

FinitionChromium

Tailles12

Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Fine woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
65/9	784152	47.2 mm	100 pièces	0.961 g
70/10	759392	47.2 mm	100 pièces	0.995 g
75/11	759402	47.2 mm	100 pièces	0.877 g
80/12	749682	47.2 mm	100 pièces	1.003 g
90/14	720182	47.2 mm	100 pièces	1.015 g
100/16	720192	47.2 mm	100 pièces	1.076 g
110/18	720202	47.2 mm	100 pièces	1.039 g
120/19	720212	47.2 mm	100 pièces	1.059 g
125/20	720222	47.2 mm	100 pièces	1.139 g
130/21	720232	47.2 mm	100 pièces	1.115 g
140/22	720242	47.2 mm	100 pièces	1.004 g
160/23	761452	47.2 mm	100 pièces	1.233 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	41.4 mm
Overall length	47.2 mm
Coating	Chromium
Needle form	B
Canu designation	44:31
Catalog designation	414200BC01RG
Further point designations	STU
Further point designations 02	STUB
Further point designations 03	S BALL
Further point designations 04	SET RT
Further point designations 05	EH
Further point designations 06	H SET
Further point designations 07	NEW RD
Further point designations 08	R STU
Technical sewing application	Double chain stitch
Point style	RG - Cloth point
Needle system	149X5
Needle system family	149X5
Pack standard	N-S-00018 – Packaging 9
Customary needle designations	TVX5
System designation 3	62X53
System designation 4	62X83
