Aiguille industrielle · 150
150 RG Chromium
150
RG
Chromium
3
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Special(s): Flat shank at 0° Recommended for: Knitwear Examples of use: Collar and cuff linking
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 720722 | 39.4 mm | 100 pièces | 0.917 g |
| 100/16 | 720732 | 39.4 mm | 100 pièces | 0.935 g |
| 110/18 | 720742 | 39.4 mm | 100 pièces | 0.954 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 34.5 mm |
| Overall length | 39.4 mm |
| Shank length | 18.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 23:10 |
| Catalog designation | 345200AC01RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Linking |
| Special(s) | Flat shank at 0° |
| Recommended for | Knitwear |
| Examples of use | Collar and cuff linking |
| Point style | RG - Cloth point |
| Needle system | 150 |
| Needle system family | 150 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | 29-C-150 |
| System designation 2 | 29 DEA |
| System designation 3 | CPX1 |
| System designation 4 | SY 6960 |
