Aiguille industrielle · 16X6

16X6 P Chromium

Système16X6

PointeP

FinitionChromium

Tailles8

Point style P - Cutting point Cutting Point • Cuts the leather perpendicular to the sewing direction at an angle of 90° • Creates a prominent decorative effect on thick and hard leather due to the slanted thread position • Thread very deep-set • Stitch holes largely filled by the thread • Suitable for very short stitches Coating Chromium Needle with standard chrome coating. Special(s): Point groove right Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
65/9	722372	38.1 mm	100 pièces	0.719 g
70/10	722382	38.2 mm	100 pièces	0.724 g
75/11	722392	38.3 mm	100 pièces	0.729 g
80/12	722402	38.3 mm	100 pièces	0.736 g
85/13	722412	38.4 mm	100 pièces	0.743 g
90/14	722422	38.4 mm	100 pièces	0.745 g
100/16	722432	38.6 mm	100 pièces	0.765 g
110/18	722442	38.7 mm	100 pièces	0.781 g

Caractéristiques techniques

Shank diameter	1.63 mm
Length butt to eye	33.9 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	P CR
Canu designation	12:05
Catalog designation	339163AC11P
Further point designations	NW
Further point designations 02	PS
Further point designations 03	SP
Further point designations 04	V
Further point designations 05	W
Technical sewing application	Double lock stitch
Stitch type class	300
Special(s)	Point groove right
Recommended for	Thin leather
Examples of use	Leather clothing, Shoes, Accessories
Point style	P - Cutting point
Needle system	16X6
Needle system family	16X6
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	34 PCR
System designation 2	287 PCR
System designation 3	TFX6
