Aiguille industrielle · 16X63 H
16X63 H R Chromium
16X63 H
R
Chromium
4
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Medium-weight to heavy woven fabrics, Medium to thick leather, Technical textiles Examples of use: Jeans >14 oz, Cushions, Belts, Awnings
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 160/23 | 757852 | 45.5 mm | 100 pièces | 1.237 g |
| 180/24 | 757862 | 45.5 mm | 100 pièces | 1.333 g |
| 200/25 | 756592 | 45.5 mm | 100 pièces | 1.169 g |
| 230/26 | 757872 | 45.5 mm | 50 pièces | 1.376 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 40.1 mm |
| Overall length | 45.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 41:05 |
| Catalog designation | 401200AC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Point style | R - Cloth point |
| Needle system | 16X63 H |
| Needle system family | 16X63 H |
| Customary needle designations | 16X113 |
| System designation 2 | 2077 |
| System designation 3 | 16X107 |
| System designation 4 | TFX63 |
