Aiguille industrielle · 1738
1738 LR Chromium
1738
LR
Chromium
6
Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 70/10 | 724162 | 38.2 mm | 100 pièces | 0.57 g |
| 75/11 | 759762 | 38.3 mm | 100 pièces | 0.754 g |
| 80/12 | 724172 | 38.3 mm | 100 pièces | 0.761 g |
| 90/14 | 724182 | 38.4 mm | 100 pièces | 0.785 g |
| 100/16 | 724192 | 38.6 mm | 100 pièces | 0.795 g |
| 110/18 | 724202 | 38.7 mm | 100 pièces | 0.815 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Shank length | 16.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | LR |
| Canu designation | 14:25 |
| Catalog designation | 339163AC01LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thin leather |
| Examples of use | Leather clothing, Shoes, Accessories |
| Point style | LR - Cutting point |
| Needle system | 1738 |
| Needle system family | 1738 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DB X F2 |
| System designation 2 | 16X230 RTW |
| System designation 3 | 16X257 LR |
| System designation 4 | 287 WH LR |
| System designation 5 | 1738 A LR |
| System designation 6 | 1738 LR |
