Aiguille industrielle · 1738A

1738A R Chromium

Système1738A

PointeR

FinitionChromium

Tailles5

Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Medium-weight woven fabrics, Leather for clothing, Artificial leather Examples of use: Jeans, Workwear, Suits, Accessories, Shoes, Leather clothing, Covers for upholstery

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
120/19	774562	38.2 mm	100 pièces	0.8 g
125/20	774572	38.3 mm	100 pièces	0.821 g
130/21	774582	38.4 mm	100 pièces	0.655 g
140/22	774592	38.5 mm	100 pièces	0.694 g
160/23	774822	38.9 mm	100 pièces	0.932 g

Caractéristiques techniques

Shank diameter	1.63 mm
Length butt to eye	33.9 mm
Shank length	13.5 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	R
Canu designation	14:20
Catalog designation	339163AC12R
Further point designations	SET
Further point designations 02	RD
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	R - Cloth point
Needle system	1738A
Needle system family	1738
Variant	A
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	DLX1
System designation 2	16X85
System designation 3	16X95
System designation 4	71X1
System designation 5	DBX95
System designation 6	DLX95
System designation 7	287 WH
System designation 8	431
System designation 9	1442
System designation 10	SY 1513
System designation 11	SY 1515
System designation 12	SY 1526
System designation 13	1738 A
System designation 14	1738 AK
