Aiguille industrielle · 175 H
175 H R Chromium
175 H
R
Chromium
6
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics Examples of use: Mattresses, Blankets
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 725102 | 55.2 mm | 100 pièces | 1.189 g |
| 100/16 | 725112 | 55.2 mm | 100 pièces | 1.16 g |
| 110/18 | 725122 | 55.2 mm | 100 pièces | 1.199 g |
| 120/19 | 725132 | 55.2 mm | 100 pièces | 1.224 g |
| 130/21 | 725142 | 55.2 mm | 100 pièces | 1.199 g |
| 150/ | 725162 | 55.2 mm | 100 pièces | 1.428 g |
Caractéristiques techniques
| Shank diameter | 1.9 mm |
|---|---|
| Length butt to eye | 48.5 mm |
| Overall length | 55.2 mm |
| Shank length | 19 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 48:14 |
| Catalog designation | 485190AC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Quilting |
| Stitch type class | 300 |
| Recommended for | Woven fabrics |
| Examples of use | Mattresses, Blankets |
| Point style | R - Cloth point |
| Needle system | 175 H |
| Needle system family | 175 H |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | USX 175 H |
| System designation 2 | SY 7610 |
