Aiguille industrielle · 190 K
190 K RG Chromium
190 K
RG
Chromium
5
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing Examples of use: Shirts, Blouses, Jeans, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 725982 | 47.8 mm | 100 pièces | 1.009 g |
| 90/14 | 725992 | 47.8 mm | 100 pièces | 1.028 g |
| 100/16 | 726002 | 47.8 mm | 100 pièces | 1.045 g |
| 110/18 | 726012 | 47.8 mm | 100 pièces | 1.074 g |
| 120/19 | 726022 | 47.8 mm | 100 pièces | 1.116 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 44.5 mm |
| Overall length | 47.8 mm |
| Shank length | 13.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 47:20 |
| Catalog designation | 445200AC02RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Button sewing |
| Stitch type class | 100, 300 |
| Recommended for | Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing |
| Examples of use | Shirts, Blouses, Jeans, Suits |
| Point style | RG - Cloth point |
| Needle system | 190 K |
| Needle system family | 190 |
| Variant | K |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | MTX 190 K |
| System designation 2 | 190 K FFG |
| System designation 3 | SY 7556 |
