Aiguille industrielle · 2091 KK
2091 KK RG Chromium
2091 KK
RG
Chromium
4
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Special(s): Short shank Recommended for: Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing Examples of use: Shirts, Blouses, Jeans, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 727072 | 50.3 mm | 100 pièces | 0.925 g |
| 90/14 | 727082 | 50.3 mm | 100 pièces | 0.906 g |
| 100/16 | 727092 | 50.3 mm | 100 pièces | 0.931 g |
| 110/18 | 727102 | 50.3 mm | 100 pièces | 0.956 g |
Caractéristiques techniques
| Shank diameter | 1.74 mm |
|---|---|
| Length butt to eye | 47 mm |
| Overall length | 50.3 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 47:30 |
| Catalog designation | 470174AC02RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Button sewing |
| Stitch type class | 100, 300 |
| Special(s) | Short shank |
| Recommended for | Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing |
| Examples of use | Shirts, Blouses, Jeans, Suits |
| Point style | RG - Cloth point |
| Needle system | 2091 KK |
| Needle system family | 2091 |
| Variant | KK |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | TQXN14 |
| System designation 2 | 29 LES |
| System designation 3 | 175X7 KK |
| System designation 4 | 175X7 KK FFG |
| System designation 5 | 175X7 KK FG |
| System designation 6 | 2091 KK |
| System designation 7 | 2091 KK FFG |
| System designation 8 | 2091 KK FG |
| System designation 9 | SY 7585 |
| System designation 10 | SY 7586 |
| System designation 11 | SY 7587 |
