Aiguille industrielle · 287 WKH
287 WKH FFG Chromium
287 WKH
FFG
Chromium
6
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Knitwear, Woven fabrics Examples of use: All kinds of embroidery
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 60/8 | 756652 | 36.8 mm | 100 pièces | 0.73 g |
| 65/9 | 756522 | 36.8 mm | 100 pièces | 0.745 g |
| 70/10 | 748862 | 36.9 mm | 100 pièces | 0.751 g |
| 75/11 | 756662 | 37 mm | 100 pièces | 0.755 g |
| 80/12 | 748872 | 37.1 mm | 100 pièces | 0.756 g |
| 90/14 | 750562 | 37.2 mm | 100 pièces | 0.597 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Shank length | 16.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SES |
| Canu designation | 13:22 |
| Catalog designation | 339163AC05FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Single and multihead embroidery |
| Stitch type class | 300 |
| Recommended for | Knitwear, Woven fabrics |
| Examples of use | All kinds of embroidery |
| Point style | FFG - Cloth point |
| Needle system | 287 WKH |
| Needle system family | 287 |
| Variant | WKH |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DBX287 WKH J |
| System designation 2 | 287 WK SES |
| System designation 3 | SY 6636 |
