Aiguille industrielle · 29 BD
29 BD RS EM Chromium
29 BD
RS EM
Chromium
5
Point style RS EM - Cloth point Sharp and very slim point • Eccentric point (at 0°) • Exact piercing of the material Coating Chromium Needle with standard chrome coating. Special(s): Eccentric point at 0°, Flat shank at 90° Recommended for: Woven fabrics Examples of use: Trousers, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 75/11 | 743662 | — | 100 pièces | 0.583 g |
| 80/12 | 723962 | — | 100 pièces | 0.715 g |
| 90/14 | 723972 | — | 100 pièces | 0.734 g |
| 100/16 | 723982 | — | 100 pièces | 0.754 g |
| 110/18 | 723992 | — | 100 pièces | 0.655 g |
Caractéristiques techniques
| Shank diameter | 2.01 mm |
|---|---|
| Length butt to eye | 36 mm |
| Shank length | 10 mm |
| Coating | Chromium |
| Needle form | N |
| Needle form description | N – Curved needle with one flat on the shank and sidewise bent blade |
| Canu point | EM |
| Canu designation | 23:83 |
| Catalog designation | 360201NC01RS EM |
| Further point designations | EM |
| Further point designations 02 | EU |
| Further point designations 03 | LG G ECC SET |
| Technical sewing application | Blind stitch |
| Stitch type class | 100 |
| Special(s) | Eccentric point at 0°, Flat shank at 90° |
| Recommended for | Woven fabrics |
| Examples of use | Trousers, Suits |
| Point style | RS EM - Cloth point |
| Needle system | 29 BD |
| Needle system family | 29 |
| Pack standard | N-S-00021 – Packaging 11 |
| Customary needle designations | 29 BC |
| System designation 2 | 29-12 |
| System designation 3 | 29-13 |
| System designation 4 | 1717 BE |
| System designation 5 | 1717 TP |
| System designation 6 | SY 7030 |
| System designation 7 | SY 7032 |
| System designation 8 | LWX1T |
