Aiguille industrielle · 34
34 R Chromium
34
R
Chromium
5
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 70/10 | 732152 | 38.2 mm | 100 pièces | 0.718 g |
| 80/12 | 732172 | 38.3 mm | 100 pièces | 0.742 g |
| 90/14 | 732192 | 38.4 mm | 100 pièces | 0.762 g |
| 100/16 | 732202 | 38.6 mm | 100 pièces | 0.785 g |
| 110/18 | 732212 | 38.7 mm | 100 pièces | 0.797 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 11:20 |
| Catalog designation | 339163AC06R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Point style | R - Cloth point |
| Needle system | 34 |
| Needle system family | 34 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | TFX1 |
| System designation 2 | PFX34 |
| System designation 3 | 16X1 |
| System designation 4 | TFX3 |
| System designation 5 | 287 |
| System designation 6 | 16X73 |
| System designation 7 | 690 |
