Aiguille industrielle · 34
34 S Chromium
34
S
Chromium
2
Point style S - Cutting point Cutting point • Cuts the leather in the sewing direction • Straight seam • Tight stitch formation with corresponding leather and stitch size • Stitch holes are elongated and clearly visible in the seam • Suitable for medium to large stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 100/16 | 731992 | 38.6 mm | 100 pièces | 0.582 g |
| 110/18 | 753742 | 38.7 mm | 100 pièces | 0.614 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Shank length | 13 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | S |
| Canu designation | 12:05 |
| Catalog designation | 339163AC06S |
| Further point designations | CR |
| Further point designations 02 | RSP |
| Further point designations 03 | NCR |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thin leather |
| Examples of use | Leather clothing, Shoes, Accessories |
| Point style | S - Cutting point |
| Needle system | 34 |
| Needle system family | 34 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | TFXF8 |
| System designation 2 | 16X2 NCR |
| System designation 3 | 287 S |
| System designation 4 | 376 S |
| System designation 5 | 606 S |
| System designation 6 | 690 S |
| System designation 7 | 1104 S |
| System designation 8 | SY 2078 |
