Aiguille industrielle · 503 SC
503 SC R GEBEDUR™
503 SC
R
GEBEDUR™
4
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle. Recommended for: Medium-weight woven fabrics, Leather for clothing, Artificial leather Examples of use: Jeans, Workwear, Suits, Leather clothing
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 763632 | 38.3 mm | 100 pièces | 0.769 g |
| 100/16 | 763642 | 38.3 mm | 100 pièces | 0.773 g |
| 110/18 | 763652 | 38.3 mm | 100 pièces | 0.784 g |
| 120/19 | 763662 | 38.3 mm | 100 pièces | 0.801 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33 mm |
| Overall length | 38.3 mm |
| Coating | GEBEDUR™ |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 08:26 |
| Catalog designation | 330163BD01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Stitch type class | 400 |
| Recommended for | Medium-weight woven fabrics, Leather for clothing, Artificial leather |
| Examples of use | Jeans, Workwear, Suits, Leather clothing |
| Point style | R - Cloth point |
| Needle system | 503 SC |
| Needle system family | 501 / 503 / 505 |
| Variant | 503 SC |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | 1807 A |
| System designation 2 | 1807-2 |
