Aiguille industrielle · 505 LG
505 LG R Chromium
505 LG
R
Chromium
2
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics Examples of use: Mattresses, Blankets
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 150/ | 734572 | 45.6 mm | 100 pièces | 1.166 g |
| 170/ | 734582 | 45.6 mm | 100 pièces | 1.15 g |
Caractéristiques techniques
| Shank diameter | 1.9 mm |
|---|---|
| Length butt to eye | 38.1 mm |
| Overall length | 45.6 mm |
| Shank length | 15.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 31:60 |
| Catalog designation | 381190AC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Quilting |
| Stitch type class | 300 |
| Recommended for | Woven fabrics |
| Examples of use | Mattresses, Blankets |
| Point style | R - Cloth point |
| Needle system | 505 LG |
| Needle system family | 501 / 503 / 505 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | LAX505 |
| System designation 2 | 500 |
| System designation 3 | 1470 |
| System designation 4 | SY 7210 |
| System designation 5 | SY 8725 |
