Aiguille industrielle · 505 SC
505 SC FFG Chromium
505 SC
FFG
Chromium
5
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Jeans, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 760202 | 38.3 mm | 100 pièces | 0.973 g |
| 90/14 | 754102 | 38.3 mm | 100 pièces | 0.756 g |
| 100/16 | 734632 | 38.3 mm | 100 pièces | 0.755 g |
| 110/18 | 754092 | 38.3 mm | 100 pièces | 0.786 g |
| 120/19 | 754082 | 38.3 mm | 100 pièces | 0.811 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33 mm |
| Overall length | 38.3 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SES |
| Canu designation | 08:28 |
| Catalog designation | 330163AC01FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Stitch type class | 300 |
| Point style | FFG - Cloth point |
| Needle system | 505 SC |
| Needle system family | 501 / 503 / 505 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | EBX755 J |
| System designation 2 | 501 SC SES |
| System designation 3 | 505 LS SES |
| System designation 4 | 755 H SES |
| System designation 5 | 1807 D SES |
| System designation 6 | SY 6481 |
