Aiguille industrielle · 5463-35
5463-35 R Chromium
5463-35
R
Chromium
3
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Medium-weight woven fabrics, Leather for clothing, Artificial leather Examples of use: Jeans, Workwear, Suits, Accessories, Shoes, Leather clothing, Covers for upholstery
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 735022 | 44.4 mm | 100 pièces | 0.884 g |
| 100/16 | 735032 | 44.4 mm | 100 pièces | 0.907 g |
| 110/18 | 735042 | 44.4 mm | 100 pièces | 0.936 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Overall length | 44.4 mm |
| Shank length | 13.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R CL |
| Canu designation | 35:46 |
| Catalog designation | 389200BC15R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Double chain stitch |
| Stitch type class | 400 |
| Recommended for | Medium-weight woven fabrics, Leather for clothing, Artificial leather |
| Examples of use | Jeans, Workwear, Suits, Accessories, Shoes, Leather clothing, Covers for upholstery |
| Point style | R - Cloth point |
| Needle system | 5463-35 |
| Needle system family | 5463-35 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | SY 7245 |
