Aiguille industrielle · 558
558 RS Chromium
558
RS
Chromium
6
Point style RS - Cloth point Sharp round point • Very slim and sharp point • Suitable for fine densely-woven fabrics • Standard point for blind stitch and Schiffli embroidery • Exact piercing of the material • Perfectly suited for very straight lockstitch seams Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics Examples of use: Trousers, Shirts, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 755002 | 39.1 mm | 100 pièces | 0.806 g |
| 90/14 | 755012 | 39.1 mm | 100 pièces | 0.865 g |
| 100/16 | 748392 | 39.1 mm | 100 pièces | 0.854 g |
| 110/18 | 749832 | 39.1 mm | 100 pièces | 0.87 g |
| 120/19 | 748402 | 39.1 mm | 100 pièces | 0.891 g |
| 130/21 | 754472 | 39.1 mm | 100 pièces | 0.914 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Overall length | 39.1 mm |
| Shank length | 11.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | SPI |
| Canu designation | 18:58 |
| Catalog designation | 339200BC05RS |
| Further point designations | R-SPI |
| Further point designations 02 | S SET |
| Further point designations 03 | SPI |
| Further point designations 04 | R-SP |
| Stitch type class | 400 |
| Recommended for | Woven fabrics |
| Examples of use | Trousers, Shirts, Suits |
| Point style | RS - Cloth point |
| Needle system | 558 |
| Needle system family | 558 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DOX558 |
| System designation 2 | 558 FR |
