Aiguille industrielle · 62X43
62X43 RG Chromium
62X43
RG
Chromium
6
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 65/9 | 758452 | 45 mm | 100 pièces | 0.87 g |
| 75/11 | 745082 | 45 mm | 100 pièces | 1.011 g |
| 80/12 | 744362 | 45 mm | 100 pièces | 1.021 g |
| 90/14 | 736262 | 45 mm | 100 pièces | 1.049 g |
| 100/16 | 736272 | 45 mm | 100 pièces | 1.059 g |
| 110/18 | 736282 | 45 mm | 100 pièces | 0.935 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Overall length | 45 mm |
| Shank length | 14.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 38:10 |
| Catalog designation | 389200BC09RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Double chain stitch, Cover chain stitch |
| Stitch type class | 400, 600 |
| Point style | RG - Cloth point |
| Needle system | 62X43 |
| Needle system family | 62X43 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | DVX43 |
| System designation 2 | DVX47 |
| System designation 3 | 62X47 |
| System designation 4 | SY 3516 |
