Aiguille industrielle · 71 L
71 L RS EL Chromium
71 L
RS EL
Chromium
2
Point style RS EL - Cloth point Sharp and very slim point • Eccentric point (at 270°) • Suitable for fine and densely woven fabrics • Standard point for blind stitch and Schiffli embroidery • Exact piercing of the material Coating Chromium Needle with standard chrome coating. Special(s): Eccentric point at 270°, Flat shank at 225° Recommended for: Knitwear Examples of use: Collar and cuff linking
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 120/19 | 738272 | 53.3 mm | 100 pièces | 0.929 g |
| 160/23 | 738292 | 58 mm | 100 pièces | 1.112 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Shank length | 14 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | EL |
| Canu designation | 47:24 |
| Further point designations | EL |
| Further point designations 02 | LF ECC SET |
| Technical sewing application | Linking |
| Stitch type class | 100, 400 |
| Special(s) | Eccentric point at 270°, Flat shank at 225° |
| Recommended for | Knitwear |
| Examples of use | Collar and cuff linking |
| Point style | RS EL - Cloth point |
| Needle system | 71 L |
| Needle system family | 71 |
| Variant | L |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | LAX71 EL |
| System designation 2 | 71 EL |
| System designation 3 | LAX71 EL |
