Aiguille industrielle · 750 SAN 1
750 SAN 1 RG Chromium
750 SAN 1
RG
Chromium
2
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Special(s): Shank notch Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 65/9 | 757262 | 37 mm | 100 pièces | 0.681 g |
| 70/10 | 769062 | 37 mm | 100 pièces | 0.727 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33 mm |
| Overall length | 37 mm |
| Shank length | 15.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Special application needle | SAN1 – SAN™ 1 for the embroidery on sturdy products (f. ex. baseball caps) |
| Canu designation | 08:30 |
| Catalog designation | 330163AC04RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Stitch type class | 400 |
| Special(s) | Shank notch |
| Recommended for | Fine knitwear, Woven fabrics, Thin leather |
| Examples of use | Shirts, Blouses, Trousers |
| Point style | RG - Cloth point |
| Needle system | 750 SAN 1 |
| Needle system family | 750 / 751 |
| Variant | SAN 1 |
| Pack standard | N-S-00017 – Standard Packaging |
