Aiguille industrielle · 81X1
81X1 RG Chromium
81X1
RG
Chromium
2
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 70/10 | 758902 | — | 100 pièces | 0.99 g |
| 125/20 | 758982 | — | 100 pièces | 0.845 g |
Caractéristiques techniques
| Shank diameter | 2.02 mm |
|---|---|
| Length butt to eye | 28.6 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 03:36 |
| Catalog designation | 286202BC09RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Overlock stitch |
| Stitch type class | 500 |
| Point style | RG - Cloth point |
| Needle system | 81X1 |
| Needle system family | 81X1 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | DCX1 |
| System designation 2 | DMX1 |
| System designation 3 | 82X1 |
