Aiguille industrielle · 854 S
854 S FG Chromium
854 S
FG
Chromium
4
Point style FG - Cloth point Medium ball point • Round point with medium ball • Suitable for loose-knit fabrics, elastic material and material containing rubber or elastane Coating Chromium Needle with standard chrome coating. Special(s): Flat shank at 135°, Threading direction from left to right Recommended for: Warp-knitted fabrics, Net lace Examples of use: Lace, Curtains, Decorative fabrics
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 750422 | — | 100 pièces | 0.499 g |
| 90/14 | 740202 | — | 100 pièces | 0.52 g |
| 100/16 | 781162 | 50.1 mm | 200 pièces | 0.53 g |
| 110/18 | 740222 | — | 100 pièces | 0.579 g |
Caractéristiques techniques
| Shank diameter | 1.4 mm |
|---|---|
| Length butt to eye | 43.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A2 – Straight needle with single groove but no scarf |
| Canu point | SUK |
| Canu designation | 46:10 |
| Catalog designation | 435140AC01FG |
| Further point designations | SUK |
| Further point designations 02 | B BALL |
| Further point designations 03 | M BALL |
| Further point designations 04 | SI |
| Further point designations 05 | BPM |
| Further point designations 06 | LAC |
| Further point designations 07 | R SUK |
| Further point designations 08 | U |
| Further point designations 09 | R KB |
| Technical sewing application | Schiffli embroidery |
| Stitch type class | 300 |
| Special(s) | Flat shank at 135°, Threading direction from left to right |
| Recommended for | Warp-knitted fabrics, Net lace |
| Examples of use | Lace, Curtains, Decorative fabrics |
| Point style | FG - Cloth point |
| Needle system | 854 S |
| Needle system family | 854 S |
| Pack standard | N-S-00855 – Packaging 38 |
| Customary needle designations | SHX1 B |
| System designation 2 | SHX1 FFG |
| System designation 3 | SHX1 FG |
| System designation 4 | 854S FG |
| System designation 5 | SY 7506 |
