Aiguille industrielle · 88
88 LR Chromium
88
LR
Chromium
1
Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thick leather Examples of use: Car seats, Cushions
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 120/19 | 740522 | 56.2 mm | 100 pièces | 1.086 g |
Caractéristiques techniques
| Shank diameter | 1.9 mm |
|---|---|
| Needle size Asia | 19 |
| Length butt to eye | 48.5 mm |
| Overall length | 56.2 mm |
| Shank length | 19 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A – Straight needle with single groove |
| Canu point | LR |
| Canu designation | 48:15 |
| Catalog designation | 485190AC05LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Stitch type class | 300 |
| Recommended for | Thick leather |
| Examples of use | Car seats, Cushions |
| Needle size | 120 Nm |
| Point style | LR - Cutting point |
| Needle system | 88 |
| Needle system family | 88 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | DUX2 LR |
| System designation 2 | 175 LR |
| System designation 3 | SY 7607 |
