Aiguille industrielle · B 27

B 27 FFG Chromium

SystèmeB 27

PointeFFG

FinitionChromium

Tailles12

Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
55/7	773862	33.1 mm	100 pièces	0.744 g
60/8	773872	33.1 mm	100 pièces	0.752 g
65/9	773882	33.1 mm	100 pièces	0.746 g
75/11	773902	33.1 mm	100 pièces	0.773 g
80/12	773912	33.1 mm	100 pièces	0.771 g
85/13	773922	33.1 mm	100 pièces	0.781 g
100/16	773942	33.1 mm	100 pièces	0.803 g
110/18	773952	33.1 mm	100 pièces	0.815 g
120/19	773962	33.1 mm	100 pièces	0.836 g
125/20	774912	33.1 mm	100 pièces	0.845 g
130/21	773972	33.1 mm	100 pièces	0.857 g
140/22	774702	33.1 mm	100 pièces	0.708 g

Caractéristiques techniques

Shank diameter	2.02 mm
Length butt to eye	28.6 mm
Overall length	33.1 mm
Shank length	10 mm
Coating	Chromium
Needle form	B
Needle form description	B1 – Straight needle with double groove and scarf
Canu point	SES
Canu designation	03:36
Catalog designation	286202BC01FFG
Further point designations	SES
Further point designations 02	L BALL
Further point designations 03	J BALL
Further point designations 04	SIN
Further point designations 05	NYR
Further point designations 06	BPL
Further point designations 07	TB
Further point designations 08	B
Further point designations 09	R K
Technical sewing application	Overlock stitch
Stitch type class	500
Point style	FFG - Cloth point
Needle system	B 27
Needle system family	B 27
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	81X1 SES
System designation 2	DCX27 J
System designation 3	DCX1 J
System designation 4	DMX1 J
System designation 5	RMX27 J
System designation 6	MY 1023 SES
System designation 7	82X1 SES
