Aiguille industrielle · B 27
B 27 FFG GEBEDUR™
B 27
FFG
GEBEDUR™
5
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 60/8 | 773982 | 33.1 mm | 100 pièces | 0.741 g |
| 70/10 | 774005 | 33.1 mm | 100 pièces | 0.751 g |
| 75/11 | 774012 | 33.1 mm | 100 pièces | 0.772 g |
| 80/12 | 774022 | 33.1 mm | 100 pièces | 0.773 g |
| 100/16 | 786902 | 33.1 mm | 100 pièces | 0.789 g |
Caractéristiques techniques
| Shank diameter | 2.02 mm |
|---|---|
| Length butt to eye | 28.6 mm |
| Overall length | 33.1 mm |
| Shank length | 10 mm |
| Coating | GEBEDUR™ |
| Needle form | B |
| Canu designation | 03:36 |
| Catalog designation | 286202BD01FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Overlock stitch |
| Stitch type class | 500 |
| Point style | FFG - Cloth point |
| Needle system | B 27 |
| Needle system family | B 27 |
