Aiguille industrielle · DBXK5
DBXK5 FFG GEBEDUR™
DBXK5
FFG
GEBEDUR™
2
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle.
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 70/10 | 784012 | 37.5 mm | 100 pièces | 0.747 g |
| 75/11 | 762762 | 37.6 mm | 100 pièces | 0.762 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Coating | GEBEDUR™ |
| Needle form | A |
| Canu designation | 13:80 |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Point style | FFG - Cloth point |
| Needle system | DBXK5 |
| Needle system family | DBXK5 |
