Aiguille industrielle · DBXK5
DBXK5 FG Chromium
DBXK5
FG
Chromium
1
Point style FG - Cloth point Medium ball point • Round point with medium ball • Suitable for loose-knit fabrics, elastic material and material containing rubber or elastane Coating Chromium Needle with standard chrome coating. Recommended for: Knitwear Examples of use: All kinds of embroidery
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 100/16 | 774942 | 38.1 mm | 100 pièces | 0.805 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Needle size Asia | 16 |
| Length butt to eye | 33.9 mm |
| Overall length | 38.1 mm |
| Shank length | 16.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SUK |
| Canu designation | 13:80 |
| Catalog designation | 339163AC20FG |
| Further point designations | SUK |
| Further point designations 02 | B BALL |
| Further point designations 03 | M BALL |
| Further point designations 04 | SI |
| Further point designations 05 | BPM |
| Further point designations 06 | LAC |
| Further point designations 07 | R SUK |
| Further point designations 08 | U |
| Further point designations 09 | R KB |
| Technical sewing application | Single and multihead embroidery |
| Stitch type class | 300 |
| Recommended for | Knitwear |
| Examples of use | All kinds of embroidery |
| Needle size | 100 Nm |
| Point style | FG - Cloth point |
| Needle system | DBXK5 |
| Needle system family | DBXK5 |
| Pack standard | N-S-00017 – Standard Packaging |
