Aiguille industrielle · DMX13

DMX13 FFG Chromium

DMX13 FFG Chromium
SystèmeDMX13
PointeFFG
FinitionChromium
Tailles6

Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear

Tailles disponibles

Taille (Nm)RéférenceLongueur totaleConditionnementPoids
65/9 749942 33.1 mm 100 pièces 0.716 g
70/10 701412 33.1 mm 100 pièces 0.725 g
75/11 701422 33.1 mm 100 pièces 0.734 g
80/12 701432 33.1 mm 100 pièces 0.739 g
90/14 701442 33.1 mm 100 pièces 0.745 g
100/16 701452 33.1 mm 100 pièces 0.767 g

Caractéristiques techniques

Length butt to eye28.6 mm
Overall length33.1 mm
Shank length8 mm
CoatingChromium
Needle formB
Needle form descriptionB1 – Straight needle with double groove and scarf
Canu pointSES
Canu designation03:28
Catalog designation286202BC04FFG
Further point designationsSES
Further point designations 02L BALL
Further point designations 03J BALL
Further point designations 04SIN
Further point designations 05NYR
Further point designations 06BPL
Further point designations 07TB
Further point designations 08B
Further point designations 09R K
Technical sewing applicationOverlock stitch
Stitch type class500
Point styleFFG - Cloth point
Needle systemDMX13
Needle system familyDMX13
Pack standardN-S-00017 – Standard Packaging
Customary needle designationsDMX13 J
System designation 282X13 SES
System designation 31886 KK SES
System designation 482X11 SES
System designation 5SY 1246
