Aiguille industrielle · FD 5
FD 5 Q Chromium
FD 5
Q
Chromium
1
Point style Q - Cutting point Square point • Cutting position at 45° • For hard and heavy material • Suitable for bag-closing Coating Chromium Needle with standard chrome coating. Recommended for: Paper, Woven material with polypropylene Examples of use: Feed bags, Transport bags, Nets
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 200/25 | 701542 | 44.8 mm | 100 pièces | 1.194 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Needle size Asia | 25 |
| Length butt to eye | 38.9 mm |
| Overall length | 44.8 mm |
| Shank length | 12.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B – Straight needle with double groove |
| Canu point | Q |
| Canu designation | 35:19 |
| Catalog designation | 389200BC18Q |
| Further point designations | SQ |
| Technical sewing application | Bag closing |
| Stitch type class | 400 |
| Recommended for | Paper, Woven material with polypropylene |
| Examples of use | Feed bags, Transport bags, Nets |
| Needle size | 200 Nm |
| Point style | Q - Cutting point |
| Needle system | FD 5 |
| Needle system family | FD 5 |
| Pack standard | N-S-00857 – Packaging 39 |
| Customary needle designations | D-5 |
| System designation 2 | BCX5 |
| System designation 3 | 3320 GR |
