Aiguille industrielle · L 83 TOP
L 83 TOP RS Chromium
L 83 TOP
RS
Chromium
5
Point style RS - Cloth point Sharp round point • Very slim and sharp point • Suitable for fine densely-woven fabrics • Standard point for blind stitch and Schiffli embroidery • Exact piercing of the material • Perfectly suited for very straight lockstitch seams Coating Chromium Needle with standard chrome coating. Special(s): Flat shank at 135°, Threading direction from left to right Recommended for: Woven fabrics, Gaz Examples of use: Embroidery, Curtains, Decorative fabrics
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 780242 | 54.3 mm | 200 pièces | 0.579 g |
| 90/14 | 780252 | 54.3 mm | 200 pièces | 0.606 g |
| 100/16 | 780262 | 54.3 mm | 200 pièces | 0.634 g |
| 110/18 | 780272 | 54.3 mm | 200 pièces | 0.661 g |
| 130/21 | 780282 | 54.3 mm | 200 pièces | 0.715 g |
Caractéristiques techniques
| Shank diameter | 1.6 mm |
|---|---|
| Length butt to eye | 47.5 mm |
| Overall length | 54.3 mm |
| Shank length | 20 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A2 – Straight needle with single groove but no scarf |
| Canu point | SPI |
| Canu designation | 47:63 |
| Catalog designation | 475160AC02RS |
| Further point designations | R-SPI |
| Further point designations 02 | S SET |
| Further point designations 03 | SPI |
| Further point designations 04 | R-SP |
| Technical sewing application | Schiffli embroidery |
| Stitch type class | 300 |
| Special(s) | Flat shank at 135°, Threading direction from left to right |
| Recommended for | Woven fabrics, Gaz |
| Examples of use | Embroidery, Curtains, Decorative fabrics |
| Point style | RS - Cloth point |
| Needle system | L 83 TOP |
| Needle system family | L 83 TOP |
| Pack standard | N-S-00855 – Packaging 38 |
| Customary needle designations | SY 7594 |
