Aiguille industrielle · MY 1014 C
MY 1014 C FG Chromium
MY 1014 C
FG
Chromium
1
Point style FG - Cloth point Medium ball point • Round point with medium ball • Suitable for loose-knit fabrics, elastic material and material containing rubber or elastane Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Knitwear, Flat-knitted fabrics Examples of use: Pullovers, Bandages
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 701762 | 43.9 mm | 100 pièces | 0.722 g |
Caractéristiques techniques
| Shank diameter | 1.47 mm |
|---|---|
| Needle size Asia | 12 |
| Length butt to eye | 38.9 mm |
| Overall length | 43.9 mm |
| Shank length | 15.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SUK |
| Canu designation | 34:18 |
| Catalog designation | 389147AC01FG |
| Further point designations | SUK |
| Further point designations 02 | B BALL |
| Further point designations 03 | M BALL |
| Further point designations 04 | SI |
| Further point designations 05 | BPM |
| Further point designations 06 | LAC |
| Further point designations 07 | R SUK |
| Further point designations 08 | U |
| Further point designations 09 | R KB |
| Technical sewing application | Flat seams |
| Stitch type class | 600 |
| Recommended for | Woven fabrics, Knitwear, Flat-knitted fabrics |
| Examples of use | Pullovers, Bandages |
| Needle size | 80 Nm |
| Point style | FG - Cloth point |
| Needle system | MY 1014 C |
| Needle system family | MY 1014 |
| Variant | C |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | SY 7257 B |
